Thermally Stable All Inorganic Cesium Lead Halide Perovskite Nanocrystals

Jusun Park1,2, Ju Young Woo1,3,*
Author Information & Copyright
1Digital Transformation R&D Department, Korea Institute of Industrial Technology (KITECH), Ansan, Korea
2Department of Energy Science, Sungkyunkwan University, Suwon, Korea
3HYU-KITECH Joint Department, Hanyang University, Ansan, Korea
*Correspondence: jywoo@kitech.re.kr

Author Contributions

J.Y.W. conceived original idea and designed the experiments and analyses. J.P. carried out experiments and characterizations under the supervision of J.Y.W. The manuscript was prepared by the contribution of all authors.

© Copyright 2022 Korea Flexible & Printed Electronics Society. This is an Open-Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/4.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.

Received: Jul 15, 2022; Revised: Aug 17, 2022; Accepted: Aug 23, 2022

Published Online: Aug 31, 2022

Graphical Abstract

jfpe-1-1-91-g9

ABSTRACT

All inorganic CsPbX3 (X is Cl, Br, or I) perovskite nanocrystals (CPX NCs) have become one of the most promising materials which can be integrated into high performance optoelectronic devices such as light emitting diodes, sensors, and solar cells. However, poor thermal stability seriously hampers successful demonstration of commercially available optoelectronic devices based on CPX NCs. In this study, we demonstrate strikingly enhanced thermal stability of CPX NCs by employing impurity metal halides during synthesis. Thermal stability of CPX NCs were investigated by microscopic and spectroscopic characterizations, and it turned out that various metal halides are effective for enhancement of thermal stability of CPX NCs. CPX NCs maintains their original structures and properties with little sign of instability such as merging and phase transformations when the NCs were synthesized by adding impurity metal halides. We finally propose plausible mechanisms on enhanced thermal stability of CPB NCs synthesized under the presence of impurity metal halides.

Keywords: CsPbX3 perovskite; Nanocrystals; Thermal stability; Merging; Phase transformation; Surface

1. INTRODUCTION

All inorganic CsPbX3, where X is Cl, Br, or I, perovskite nanocrystals (CPX NCs) have gained immense interest because of their exceptionally high photoluminescence (PL) quantum yield (QY) [1,2]. Defect-tolerant properties resulted from the presence of Pb element make them not to need surface passivation to achieve high PL QY [3,4]. In addition, mass-producible simple colloidal synthesis, solution processibility, and ease of band gap tuning enabled by composition engineering make the CPX NCs highly attractive in various optoelectronic applications such as light emitting diodes (LEDs) [4-7], photovoltaic cells [8,9], and detectors [10].

However, further progress of CPX NC-based optoelectronic devices have been retarded due to instability of CPX NCs such as merging [11], easy desorption of surface ligands [12] and thermal degradation [13]. For example, high PL QY of CPX NCs rapidly diminishes since nanometer-sized domain of CPX NCs become larger by merging process [11]. When the domain size become larger, radiative recombination of charge carriers is hindered, resulting in decrease of PL QY [17]. Also colloidally synthesized CPX NCs easily decompose due to weak binding of ligands on surfaces [12].

Recently merging and ligand desorption issues could be notably alleviated by development of surface engineering of CPX NCs [12,14,15]. Removal of merging-vulnerable facets was effective for suppression of merging, and introduction of new ligand system enhanced binding energy on surfaces [16]. However, thermal instability issue, which should be overcome for realization of optoelectronic devices working at high temperature, has not been addressed clearly.

Here, we demonstrate remarkably enhanced thermal stability of CPX NCs. Colloidal CPX NCs prepared with the presence of impurity metal halides showed high thermal stability with markedly suppressed merging and phase transformation while CPX NCs synthesized without impurity metal halides exhibited drastic merging and phase transformation at elevated temperature. By investigating various impurity metal halides, we could extent the list of metal halides which are effective for enhancement of thermal stability. Finally we proposed mechanism on enhancement of thermal stability of CPX NCs.

2. METHODS

For the synthesis, cesium oleate solution was prepared by mixing 2.5 mmol of cesium carbonate, 2.5 mL of oleic acid (OA) in 40 mL of 1-octadecene (ODE). The temperature was set to 100°C for degassing, and then the cesium oleate solution was kept at 150°C before injection.

CsPbX3 (CPX where X is Br or I) NCs were synthesized basically following the previously reported procedure with some modifications [1,11]. First, 3.76 mmol of PbX2, 10 mL of OA, and 10 mL of oleylamine (OLA) were mixed in 100 mL of ODE. Then the solution was degassed for 2 h at 100°C. Next, temperature of the solution was raised to 170°C under Ar flow, and 8 mL of cesium oleate solution was swiftly injected. After 10 s, the reaction flask is rapidly cooled to room temperature by immersing in a water bath. For the synthesis of CPX under the presence of impurity metal halides, 4.2 mmol of impurity metal halides (e.g., ZnX2, SnX2, InX3, and GeX2) were introduced in the flask containing PbX2, OA, and OLA, and other procedures were conducted in same manner with the synthesis of pristine CPX NCs.

The synthesized NCs were purified by centrifugations. The reaction crude solution was centrifuged at 10,000 rpm for 10 min. And then the precipitate was redisperesed in toluene, and centrifugation was performed again (13,000 rpm for 30 min). The resulting precipitate was redispersed in hexane, and the solution was centrifuged at 6,000 rpm for 10 min. Finally, the supernatant was collected and filtered using syringe filter. The resulting NCs were stored under inert conditions.

For thermal stability test, CPX NCs were deposited on glass substrates by drop casting. After deposition the CPX NC films were placed on a hot plate at desired temperature for thermal stability. We note that all the thermal stability tests were performed in inert conditions.

3. RESULTS AND DISCUSSION

Fig. 1(a) shows absorption and PL spectra of CsPbBr3 NCs synthesized based on previously reported procedures without impurity metal halides (pristine-CPB NCs) [1]. The PL peak position is around 512 nm (green color, see the inset in Fig. 1(a)) with very narrow full width at half maximum (FWHM) of 21 nm possibly due to very weak quantum confinement effect resulted from their larger size than exciton Bohr size [2]. From analysis using transmission electron microscopy (TEM), it was confirmed that fresh pristine-CPB NCs are cube shape with average size around 10 nm, which is in accordance with earlier studies [2], and they were individually well distributed on a TEM grid (Fig. 1(b)).

jfpe-1-1-91-g1
Fig. 1. (a) Absorption and PL spectra, (b) TEM image and (c) XRD patterns of pristine-CPB NCs with reference patterns (cubic phase, ICSD 98-002-9073). Scale bar in (b) is 100 nm.
Download Original Figure

XRD patterns were collected using a CPB NC film on a glass substrate, and the XRD patterns revealed the crystallographic structures of CPB NCs (cubic phase) as shown in Fig. 1(c). Patterns were noticeably broad due to nanometer-size of CPB NCs [11,13].

Thermal stability of CPB NCs is a very important property because the temperature of various optoelectronic devices (solar cells, LEDs, and detectors) rises during operation. Therefore, in order to investigate the thermal stability of CPB NCs, we heated CPB NC films. After heating for 1 h at 200°C, the XRD patterns of pristine-CPB NCs were significantly sharpened due to increased size (Fig. 2(a)). Direct visualizations based on TEM analysis confirmed markedly enlarged structures of pristine-CPB NCs after heating. Approximately 10 nm average size increased (Fig. 2(b)) to ~300 nm after thermal stability test as shown in Fig. 2(c).

jfpe-1-1-91-g2
Fig. 2. XRD patterns of (a) pristine-CPB NCs before and after heating at 200°C. TEM images of pristine-CPB NCs (b) before and (c) after heating. Scale bars are 50 nm. It is noted that XRD patterns of pristine-CPB after heating in (a) was taken from the data shown in Fig. 1(c).
Download Original Figure

Previously it has been reported that CPB NCs merge under air condition [11]. Since PL QY drastically decreases upon merging of CPB NCs due to dissociation of charge carriers [17], merging of the NCs must be prevented to fabricate high-performance light-emitting devices. It was suggested that lacking of steric hindrance on surfaces should lead to the formation of directionally merged structures of CPB NCs [16]. We believe similar mechanism could play in merging of CPB NCs after heating.

We postulated that thermal stability of CPB NCs against merging can be improved by synthesizing the NCs with surface structures having less exposed (110) surfaces because (110) surface was known to be the site where merging exclusively initiates due to lack of steric hindrance, indicating absence of organic ligands [16]. One of the way to effectively synthesize the CPB NCs without (110) surfaces is adding impurity metal halides during the synthesis. When impurity metal halides present during the synthesis, oleylammonium- passivated CPB NCs can be formed. At the same time, exposure of (110) surface can be highly suppressed since formation of (110) surface becomes energetically unfavored [16]. Therefore we explored the thermal stability of CPB NCs synthesized with addition of impurity metal halides (e.g., ZnBr2) as shown in Fig. 3.

jfpe-1-1-91-g3
Fig. 3. Schematic illustration of the synthesis of CPB NCs.
Download Original Figure

As shown in Fig. 4(a), XRD patterns of as-prepared CPB NCs synthesized under the presence of ZnBr2 (ZnBr2-CPB NCs) are very similar compared to XRD patterns of as-prepared pristine-CPB NCs. However, the results were in stark contrast after thermal stability test. While XRD patterns of pristine-CPB NCs become significantly sharpened (Fig. 2(a)), the XRD patterns of ZnBr2-CPB NCs showed nearly no change even after heating, indicating merging of NCs was effectively suppressed (Fig. 4(a)). Changes of peak ratios after thermal stability test in XRD patterns can be attributed to rearrangement of NC ensemble after heating. TEM analysis clearly demonstrated almost-perfectly suppressed merging after thermal stability test at 200°C (Fig. 4(b) and Fig. 4(c)). We note that ZnBr2-CPB NCs were also stable even for prolonged heating time (Fig. 5(a)). After heating, PL QY of ZnBr2-CPB NCs could be retained much better compared to PL QY of pristine-CPB due to effectively suppressed merging in ZnBr2-CPB NCs (Fig. 5(b)). It is noted that Zn element was not detected in ZnBr2-CPB because Zn-related species were removed during purifications due to absence of direct coordination (Fig. 5(c)).

jfpe-1-1-91-g4
Fig. 4. XRD patterns of (a) ZnBr2-CPB NCs, TEM images of ZnBr2-CPB NCs (b) before and (c) after thermal stability test at 200°C. Scale bars in (b) and (c) are 50 nm.
Download Original Figure
jfpe-1-1-91-g5
Fig. 5. (a) XRD patterns of ZnBr2-CPB NCs after thermal stability test for prolonged heating time, (b) PL QY values of pristine- and ZnBr2- CPB NCs recorded as a function of heating time at 200°C, (c) XPS Zn 2p spectrum of ZnBr2-CPB NCs after purifications. No Zn was detected.
Download Original Figure

In order to investigate the effect of other metal halides, CPB NCs were synthesized with addition of various metal halides such as SnBr2, InBr3, and GaBr2 (The resulting CPB are denoted hereafter as SnBr2- CPB, InBr3-CPB, and GeBr2-CPB, respectively). SnBr2-, InBr3-, and GeBr2-CPB NCs showed XRD patterns of cubic phase CsPbBr3 crystals (Fig. 6). Importantly, thermal stability was considerably improved in all SnBr2-, InBr3-, and GaBr2-CPB NCs, and the fact was clearly demonstrated in broad XRD patterns of CPB NCs even after heating at 200°C (Fig. 6). With the best of knowledge, this is the first demonstration of significantly enhanced thermal stability in CPB NCs synthesized with various impurity metal halides.

jfpe-1-1-91-g6
Fig. 6. XRD patterns of (a) SnBr2-CPB NCs, (b) InBr3-CPB NCs, and (c) GeBr2-CPB NCs before and after thermal stability test at 200°C.
Download Original Figure

Based on experimental evidences, we propose mechanism on enhancement of thermal stability in CPB NCs prepared using impurity metal halides (Fig. 7). Similar to earlier studies, which demonstrated merging process occurred under ambient condition, presence of (110) surface may have much to do with merging, and the merging should be a heat-driven process. However, merging can be strikingly suppressed by minimizing the exposure of (110) surfaces of CPB NCs, and such thermally stable surface structures can be obtained by introducing various metal halides during the synthesis of CPB NCs.

jfpe-1-1-91-g7
Fig. 7. Proposed mechanism on merging process upon heating in CPB NCs prepared (left) without or (right) with impurity metal halides.
Download Original Figure

In addition to instability on merging of CPB NCs, one of the most widely reported instability in perovskite NCs is phase instability observed in CsPbI3 (CPI) NCs. Although cubic phase (black phase) is highly desired in CPI NCs, the cubic phase easily transforms to undesired orthorhombic phase (yellow phase) under various stimuli [9,18,20]. Therefore, to test the effect of metal halides on thermal stability of CPI NCs, we synthesized CPI NCs with or without impurity metal halide (e.g., ZnI2).

As reported in many previous studies, cubic phase of as-prepared pristine-CPI NCs was very unstable [9,20]. Initially obtained cubic phase rapidly transformed to orthorhombic phase upon heating as clearly evidenced in XRD patterns of pristine-CPI NCs (Fig. 8(a)). However, surprisingly, cubic phase of ZnI2-CPI NCs was very well retained, as shown in Fig. 8(b), corroborating the fact the phase stability of CPI NCs was strikingly improved by adding impurity metal halides during synthesis.

jfpe-1-1-91-g8
Fig. 8. XRD patterns of (a) pristine- and (b) ZnI2-CPI NCs before and after thermal stability test at 150°C.
Download Original Figure

4. CONCLUSION

In conclusion, we investigate the thermal stability of all inorganic CPX NCs (X=Br, I). CPB NCs synthesized through a typical hot-injection method exhibited poor thermal stability. The NCs significantly merged upon heating at elevated temperature. However, addition of impurity metal halides (e.g., ZnBr2, SnBr2, InBr3, and GeBr2) effectively help to enhance stability against merging. And the enhanced stability against merging could be interpreted in suppressed formation of (110) surfaces, which have nearly no steric hindrance, under the presence of impurity metal halides. Same strategy also worked very effectively to enhance the phase stability of CPI NCs. Cubic phase of CPI NCs synthesized with impurity metal halides become very stable against heating. We believe our work on enhancing the thermal stability of CPX NCs provide new insight to prepare high performance optoelectronic devices based on CPX NCs with prolonged operating lifetime.

Funding

This research was supported by the grant (2021R1F1A1056194) funded by National Research Foundation of Korean and the grant (RS-2022-00144108) funded by Ministry of Trade, Industry and Energy of Korea government.

Declarations of Competing Interests

The authors declare that they have no competing interests.

REFERENCES

[1].

Protesescu, L.; Yakunin, S.; Bodnarchuk, M. I.; Krieg, F.; Caputo, R.; Hendon, C. H.; Yang, R. X.; Walsh, A.; Kovalenko, M. V. Nanocrystals of Cesium Lead Halide Perovskites (CsPbX3, X = Cl, Br, and I): Novel Optoelectronic Materials Showing Bright Emission with Wide Color Gamut. Nano Lett. 2015, 15, 3657-4240.

[2].

Swarnkar, A.; Chulliyil, R.; Ravi, V. K.; Irfanullah, M.; Chowdhury, A.; Nag, A. Colloidal CsPbBr3 Perovskite Nanocrystals: Luminescence beyond Traditional Quantum Dots. Angew. Chem. 2015, 127, 15644-15648.

[3].

Brandt, R. E.; Stevanovic, V.; Ginley, D. S.; Buonassisi, T. Indentifying Defect-Tolerant Semiconductors With High Minority-Carrier Lifetimes: Beyond Hybrid Lead Halide Perovskites. MRS Commun. 2015, 5, 265-275.

[4].

Dirin, D. N.; Protesescu, L.; Trummer, D.; Kochetygov, I. V.; Yakunin, S.; Krumeich, F.; Stadie, N. P.; Kovalenko, M. V. Harnessing Defect-Tolerance at the Nanoscale: Highly Luminescent Lead Halide Perovskite Nanocrystals in Mesoporous Silica Matrixes. Nano Lett. 2016, 16, 5866-5874.

[5].

Wang, H.; Zhang, X.; Wu, Q.; Cao, F.; Yang, D.; Shang, Y.; Ning, Z.; Zhang, W.; Zheng, W.; Yan, Y.; Kershaw, S. V.; Zhang, L.; Rogach, A. L.; Yang, X. Trifluoroacetate Induced Small-Grained CsPbBr3 Perovskite Films Result in Efficient And Stable Light-Emitting Devices. Nat. Commun. 2019, 10, 1-10.

[6].

Zhang, X.; Xu, B.; Zhang, J.; Gao, Y.; Zheng, Y.; Wang, K.; Sun, X. W. All-inorganic Perovskite Nanocrystals for High-Efficiency Light Emitting Diodes: Dual-Phase CsPbBr3-CsPb2Br5 Composites. Adv. Funct. Mater. 2016, 26, 4595-4600.

[7].

Wan, Q.; Huang, L.; Kong, L.; Zhang, Q.; Zhang, C.; Liu, M.; Liao, X.; Zhan, W.; Zheng, W.; Yuan, C.; He, M.; Li, L. High-Efficiency Semitransparent Light-Emitting Diodes with Perovskite Nanocrystals. ACS Appl. Mater. Interfaces. 2022, 14, 19697- 19703.

[8].

Ma, S.; Yuan, G.; Zhang, Y.; Yang, N.; Li, Y.; Chen, Q. Development of Encapsulation Strategies towards the Commercialization of Perovskite Solar Cells. Energy Environ. Sci. 2022, 15, 13-55.

[9].

Swarnkar, A.; Marshall, A. R.; Sanehira, E. M.; Chernomordik, B. D.; Moore, D. T.; Christians, J. A.; Chakrabarti, T.; Luther, J. M. Quantum Dot–Induced Phase Stabilization of α-CsPbI3 Perovskite for High-Efficiency Photovoltaics. Science. 2016, 354, 92-95.

[10].

Ramasamy, P.; Lim, D. H.; Kim, B.; Lee, S. H.; Lee, M. S.; Lee, J. S. All-Inorganic Cesium Lead Halide Perovskite Nanocrystals for Photodetector Applications. Chem. Commun. 2016, 52, 2067- 2070.

[11].

Woo, J. Y.; Kim, Y.; Bae, J.; Kim, T. G.; Kim, J. W.; Lee, D. C.; Jeong, S. Highly Stable Cesium Lead Halide Perovskite Nanocrystals through in situ Lead Halide Inorganic Passivation. Chem. Mater. 2017, 29, 7088-7092.

[12].

De Roo, J.; Ibáñez, M.; Geiregat, P.; Nedelcu, G.; Walravens, W.; Maes, J.; Martins, J. C.; Driessche, I. V.; Kovalenko, M. V.; Hens, Z. Highly Dynamic Ligand Binding and Light Absorption Coefficient of Cesium Lead Bromide Perovskite Nanocrystals. ACS Nano. 2016, 10, 2071-2081.

[13].

Boote, B. W.; Andaraarachchi, H. P.; Rosales, B. A.; Blome-Fernández, R.; Zhu, F.; Reichert, M. D.; Santra, K.; Li, J.; Petrich, J. W.; Vela, J.; Smith, E. A. Unveiling the Photo-and Thermal-Stability of Cesium Lead Halide Perovskite Nanocrystals. Chem. Phys. Chem. 2019, 20, 2647-2656.

[14].

Imran, M.; Ijaz, P.; Goldoni, L.; Maggioni, D.; Petralanda, U.; Prato, M.; Almeida, G.; Infante, I.; Manna, L. Simultaneous Cationic and Anionic Ligand Exchange for Colloidally Stable CsPbBr3 Nanocrystals. ACS Energy Lett. 2019, 4, 819-824.

[15].

Krieg, F.; Ochsenbein, S. T.; Yakunin, S.; Ten Brinck, S.; Aellen, P.; Süess, A.; Clerc, B.; Guggisberg, D.; Nazarenko, O.; Shynkarenko, Y.; Kumar, S.; Shih, C.; Infante, I.; Kovalenko, M. V. Colloidal CsPbX3 (X= Cl, Br, I) Nanocrystals 2.0: Zwitterionic Capping Ligands for Improved Durability and Stability. ACS Energy Lett. 2018, 3, 641-646.

[16].

Yoo, D.; Woo, J. Y.; Kim, Y.; Kim, S. W.; Wei, S. H.; Jeong, S.; Kim, Y. H. Origin of the Stability and Transition from Anionic to Cationic Surface Ligand Passivation of All-Inorganic Cesium Lead Halide Perovskite Nanocrystals. J. Phys. Chem. Lett. 2020, 11, 652-658.

[17].

Cho, H.; Jeong, S. H.; Park, M. H.; Kim, Y. H.; Wolf, C.; Lee, C. L.; Heo, J. H.; Sadhanala, A.; Myoung, N.; Yoo, S.; Im, S. H.; Friend, R. H.; Lee, T. W. Overcoming the Electroluminescence Efficiency Limitations of Perovskite Light-Emitting Diodes. Science. 2015, 350, 1222-1225.

[18].

Dutta, A.; Dutta, S. K.; Adhikari, S. D.; Pradhan, N. Phase-Stable CsPbI3 Nanocrystals: The Reaction Temperature Matters. Angew. Chem. Int. Ed. 2018, 57, 9083-9087.

[19].

Pan, L.; Zhang, L.; Qi, Y.; Conkle, K.; Han, F.; Zhu, X.; Box, D.; Shahbazyan, T. V.; Dai, Q. Stable CsPbI3 Nanocrystals Modified by Tetra-n- butylammonium Iodide for Light-Emitting Diodes. ACS Appl. Nano Mater. 2020, 3, 9260-9267.
